Video Conferencing System VC4

University is demanding new collaboration projects e.g. webinars, online chats with subject-matter experts, collaboration on project where several specialist are involved. The best solution for them is online conversation where they can utilize all advantege of VideoConferencing. TRIUMPH BOARD Video Conferencing System VC4 will connect them all, anywhere they are.

The TRIUMPH BOARD Video Conferencing System VC4 provides uniquely budget-friendly, 4-site, high-performance MCU, real-time full HD video streaming and HD real-time content sharing with recording
capability.

Wide-angle Full HD camera with 16x optical zoom ensures no one is left out of the shot, a sophisticated audio processing technology microphone array produces true-to-life sound, a sleek and a compact system design
enables easy integration with TRIUMPH BOARD LED LCD Series for an advanced total solution.

Software add-ons:

TRIUMPH Meeting- mobility software to connect to desktops, laptops, tablets and mobile phones

TRIUMPH Link – share live images and snapshots directly from your mobile device

TRIUMPH Share – wirelessly share content from your PC at any time during a call

TRIUMPH Player – playback recorded meetings or convert the video fi les to a different format

WebTool application – handy integration remote access tools

Contact Us

If you want to purchase TRIUMPH BOARD products or find out more information, please contact us and we will connect you with an authorized distributor near to you.

Contact

TRIUMPH Meeting

TRIUMPH Link

Product videos

  • 4 – Site System
  • License upgrade to 6, 8 or 10 points
  • Full HD video & HD content sharing
  • Easy connection set up
  • One-touch recording
  • High definition (+/- 100° pan, +/- 25° tilt) camera

  • High-efficiency lost packet recovery technology
  • Microphone array advanced audio processing technology
  • Software add-ons: TRIUMPH Meeting, TRIUMPH Link, TRIUMPH Share, TRIUMPH Player, WebTool application
EAN: 8592580083150
Accessories in the box: Main system unit (codec), PTZ HD camera, microphone array, IR remote control with bateries, power supply, cables, warranty card, quick instalation card
Communications: H.323 and SIP standards/ SIP TLS/ 64Kbps~4Mbps/RJ45 network LAN (10/100/1000)/Manual bandwidth settings/Content sharing capability from all sites
Camera: Support for single camera/pan/tilt/zoom camera /2-megapixel CMOS sensor/16x optical zoom; ±100° pan; ±25° tilt/FOV 61° (H); 35° (V); 67° (Diagonal)
People video resolutions: HD1080p (1920 x 1080)/HD720p (1280 x 720)/480p (848 x 480)/4CIF (704 x 576)/SIF (352 x 240), CIF (352 x 288)/All resolutions at 30fps
Supported Content video resolutions: HD1080p (1920 x 1080)/ WSXGA+ (1680 x 1050)/ SXGA (1280 x 1024)/ WXGA (1280 x 768)/ HD720p (1280 x 720)/ XGA (1024 x 768)/ SVGA (800 x 600)/ D1 (720 x 480)/ VGA (640 x 480)/ Output resolutions: HD1080p (1920 x 1080) up to 30fps
Video standards: H.264, H.264 HP, H.264 SVC, H.263+, H.263, H.261/H.239 dual video streams, BFCP content sharing
Video inputs: HD camera, VGA, DVI (HDMI)
Video outputs: HDMI, VGA
Audio standards: G.711, G.722, G.722.1, G.728, G.722.1C
Audio features: Automatic gain control (AGC), Advanced noise reduction, Acoustic echo cancellation (AEC)
Audio inputs: Microphone daisy chain up to 4, Line-in (3.5 mm), DVI (HDMI)
Audio outputs: HDMI, Line-out (3.5 mm)
Other supported standards: H.224, H.225, H.245, H281, H.323 Annex Q, H.460
User interface: Supports single and dual monitor display/ Multiple layout styles/ Display / edit site name/ User-friendly OSD (27 supported languages: English, Czech, Danish, Arabic, Bulgarian, Croatian, Dutch, Finnish, French, German, Greek, Hebrew, Hungarian, Italian, Latvian, Norwegian, Polish, Portuguese-Brazil, Romanian, Russian, Serbian, Slovak, Slovenian, Spanish, Swedish, Turkish, Ukranian)
Network: 10/100/1000Mbps/ NAT/ firewall traversal/ High Efficiency Lost Packet Recovery (HELPeR™)/ API support via Telnet/ Wake-on-LAN (WOL) support/ IPv4 and IPv6 support/ Network Test/ QoS
Security: AES (Advanced Encryption Standard) function(128-bit)/ Password protection for system setting/ Password protection for remote system management
Web management tool: Remote management/ Live monitoring/ Firmware update/ Phonebook download/ upload/ edit Restore system settings
Value-added features: Speed dialing via hot keys(10sets)/Camera presets (10positions)/Network Time Protocol(NTP)/License upgrade to 6,8,10 points/ TRIUMPH Share support/ TRIUMPH Link support
Power Supply: AC 100V~240V, 50/60Hz Consumption: EIAJ 12V, 4A
Environmental data: Operation temperature: 0~40°C Operation humidity: 20%~80% Storage temperature: -20~60°C Storage humidity: 20%~80%
Gross Weight: 5.98 kg (13.19 lbs)
Dimensions: Package: 378 x 297 x 224 mm
Dimensions: Main system (codec): 320 x 262.7 x 37.2 mm
Dimensions: Camera: 122.3 x 122.3 x 159.5 mm
Dimensions: Microphone array: 131.9 x 118.6 x 25.5 mm
Datasheet Video Con System VC4 EN 2016Download
Datasheet Video Con System VC4 US 2016Download
Datasheet Video Con System VC4 DE 2016Download
Education Catalog EN 2016Download
Education Catalog US 2016Download
